Type: REMOTE I/O COMBINED MODULE
Series: CC-LINK IE FIELD NETWORK
Serial Number:
Product Details: PLC CC-Link IE Field DC Input +COM Transistor sink, 32 points, FCN
DIGITAL I/O MODULE
SERIES CC-LINK IE FIELD NETWORK
TYPE REMOTE I/O COMBINED MODULE
POWER SUPPLY (V) 24
CURRENT TYPE DC
OCCUPIED STATIONS 1
INTEGRATED DIGITAL INPUTS 16
INTEGRATED DIGITAL OUTPUTS 16
RATED INPUT VOLTAGE (VDC) 24
RATED LOAD VOLTAGE (VDC) 12/24
OUTPUT TYPE TRANSISTOR
OUTPUT LOGIC SINK
WIRING CONNECTOR
INT. CURRENT CONSUMPTION (A) 0,11
PRODUCT DIMENSIONS & WEIGHT
WIDTH (MM) 163
HEIGHT (MM) 50
DEPTH (MM) 68
WEIGHT (KG) 0,26
ORDER CODES
EUROPEAN ORDER CODE 296517
GLOBAL ORDER CODE 1WF028
CLASSIFICATION DATA
PRODUCT HIERARCHY IAD50305
CLASS DESCRIPTION FA-MOD PLC: Digital I/O Module
EXTERNAL MATERIAL GROUP Standard Material
AVAILABILITY
LOGISTIC CLASS C
PACKAGING DIMENSIONS & WEIGHT
GROSS WEIGHT 0.38 KG
VOLUME 1.688 CDM
LENGTH 25 CM
WIDTH 7,5 CM
HEIGHT 9 CM
COMMODITY / IMPORT CODE
COMMODITY CODE 85389099
COUNTRY OF ORIGIN JP
ENVIRONMENTAL
ROHS COMPLIANCE COMPLIANT
REACH LIMIT EXCEEDED NO
DANGEROUS GOODS REGULATIONS NO
