Type: REMOTE TRANSISTOR OUTPUT
Series: CC-LINK IE FIELD NETWORK
Serial Number:
Product Details: PLC CC-Link IE Field Extension Module; 16 transistor outputs; sink; spring clamp
DIGITAL OUTPUT MODULE
SERIES CC-LINK IE FIELD NETWORK
TYPE REMOTE TRANSISTOR OUTPUT
OCCUPIED STATIONS 1
INTEGRATED DIGITAL OUTPUTS 16
OUTPUT TYPE TRANSISTOR
OUTPUT LOGIC SINK
RATED LOAD VOLTAGE (VDC) 12-24
WIRING SPRING CLAMP
INT. CURRENT CONSUMPTION (A) 0,03
PRODUCT DIMENSIONS & WEIGHT
WIDTH (MM) 93
HEIGHT (MM) 50
DEPTH (MM) 68
WEIGHT (KG) 0,19
ORDER CODES
EUROPEAN ORDER CODE 297156
GLOBAL ORDER CODE 1WF021
CLASSIFICATION DATA
PRODUCT HIERARCHY IAD50305
CLASS DESCRIPTION FA-MOD PLC: Digital Output Module
EXTERNAL MATERIAL GROUP Standard Material
AVAILABILITY
LOGISTIC CLASS C
PACKAGING DIMENSIONS & WEIGHT
GROSS WEIGHT 0.3 KG
VOLUME 0 CDM
LENGTH 0 CM
WIDTH 0 CM
HEIGHT 0 CM
COMMODITY / IMPORT CODE
COMMODITY CODE 85389099
COUNTRY OF ORIGIN JP
CAMPAIGNS
SELLING STATUS Standard
ENVIRONMENTAL
ROHS COMPLIANCE COMPLIANT
REACH LIMIT EXCEEDED NO
DANGEROUS GOODS REGULATIONS NO
