Type: NF-H TYPE (HIGH-PERFORMANCE)
Series: WS-V SERIES – MCCB
Serial Number: 255136
Product Details: Circuit breaker 3pole. Ir = 125 – 160A; Icu = Ics = 65kA at AC 440V
MOULDED-CASE CIRCUIT BREAKER
SERIES WS-V SERIES – MCCB
TYPE NF-H TYPE (HIGH-PERFORMANCE)
NUMBER OF POLES 3
CURRENT TYPE AC/DC
RATED VOLTAGE (V) 690
BREAKING CAPACITY AT 400V (KA) 75
PRODUCT DIMENSIONS & WEIGHT
WIDTH (MM) 105
HEIGHT (MM) 165
DEPTH (MM) 92
WEIGHT (KG) 1,6
ORDER CODES
EUROPEAN ORDER CODE 255136
GLOBAL ORDER CODE 2CM311A00000F
CLASSIFICATION DATA
PRODUCT HIERARCHY IAN10201
CLASS DESCRIPTION FA-MCCB: Moulded-Case Circuit Breaker
EXTERNAL MATERIAL GROUP Standard Material
AVAILABILITY
LOGISTIC CLASS C
PACKAGING DIMENSIONS & WEIGHT
GROSS WEIGHT 1.747 KG
VOLUME 4.531 CDM
LENGTH 17 CM
WIDTH 13 CM
HEIGHT 20,5 CM
COMMODITY / IMPORT CODE
COMMODITY CODE 85362010
COUNTRY OF ORIGIN JP
LIFE CYCLE
PREDECESSOR 212126
CAMPAIGNS
SELLING STATUS Standard
ENVIRONMENTAL
ROHS COMPLIANCE COMPLIANT
REACH LIMIT EXCEEDED NO
DANGEROUS GOODS REGULATIONS NO
