Type: I/O COMBINED MODULE
Series: MELSEC-L SERIES
Serial Number:
Product Details: SPS,L-Series I/O Module;32 In/32 Outputs;Transist.;24VDC In/12-24VDC Out;Sink
DIGITAL I/O MODULE
SERIES MELSEC-L SERIES
TYPE I/O COMBINED MODULE
POWER SUPPLY (V) 12/24
CURRENT TYPE DC
OCCUPIED I/O POINTS ON PLC 32
INTEGRATED DIGITAL INPUTS 32
INTEGRATED DIGITAL OUTPUTS 32
RATED INPUT VOLTAGE (VDC) 24
RATED LOAD VOLTAGE (VDC) 12/24
OUTPUT TYPE TRANSISTOR
OUTPUT LOGIC SINK
WIRING CONNECTOR
INT. CURRENT CONSUMPTION (A) 0,16
PRODUCT DIMENSIONS & WEIGHT
WIDTH (MM) 28,5
HEIGHT (MM) 90
DEPTH (MM) 95
WEIGHT (KG) 0,12
ORDER CODES
EUROPEAN ORDER CODE 269671
GLOBAL ORDER CODE 1WC206
CLASSIFICATION DATA
PRODUCT HIERARCHY IAD510
CLASS DESCRIPTION FA-MOD PLC: Digital I/O Module
EXTERNAL MATERIAL GROUP Standard Material
AVAILABILITY
LOGISTIC CLASS C
PACKAGING DIMENSIONS & WEIGHT
GROSS WEIGHT 0.184 KG
VOLUME 1.31 CDM
LENGTH 15,5 CM
WIDTH 13 CM
HEIGHT 6,5 CM
COMMODITY / IMPORT CODE
COMMODITY CODE 85389099
COUNTRY OF ORIGIN JP
CAMPAIGNS
SELLING STATUS Standard
ENVIRONMENTAL
ROHS COMPLIANCE COMPLIANT
REACH LIMIT EXCEEDED NO
DANGEROUS GOODS REGULATIONS NO
