Type: FR-F800-E INVERTER
Series: FR-F800 SERIES
Serial Number: 307219
Product Details: Product Details
The FR-F800 is a pump and fan control VFD optimized for maximum energy saving. Equally at home in an industrial environment or as part of an integrated HVAC system, FR‑F800 can also be used as a cost-effective drive for controlling other types of lighter duty constant torque loads.
Convenient installation without an enclosure
Standard USB port – for simple set-up using a memory stick
Real-time clock – Enables time stamping of trip messages for easy diagnostics
’Load detection’ system – Detects broken drive belts and other mechanical problems
Anti-Windmill function – avoids costly damage to drive and motor by smoothly controlling loads which are already spinning before start-up
Specifications
Attribute Value
Power Rating 18.5 kW
Phase 3
Supply Voltage 400 V ac
Current Rating 38 A
Output Frequency 50/60Hz
For Use With Compressor, Fan Application, Pump
Series FR-F800
IP Rating IP20
Field Bus Communication Type BACnet
Drive Type PID Control
Control Panel Yes
Ambient Temperature -10 → +40 (SLD) °C, -10 → +50 (LD) °C
Filter Included Yes
Overall Depth 190mm
Function Motor Control
Mounting Type Wall Mount
Overall Length 220mm
Interface Ethernet
Overall Width 300mm
