Mitsubishi FR-A840-00250-E2-60R2R Inverter AC; Pn: 5,5-11kW; 3×380-500V;In max: 25A;(7,5kW; 17A); IP20

1,415.00

Close
Price Summary
  • 1,415.00
  • 1,415.00
  • 1,415.00
In Stock
Highlights:

Type: FR-A800-R2R (FOR ROLL TO ROLL)

Compare
SKU: FR-A840-00250-E2-60R2R Categories: ,
Description

Type: FR-A800-R2R (FOR ROLL TO ROLL)

Series: FR-A800 PLUS SERIES

Serial Number: 412447

Product Details: Inverter AC; Pn: 5,5-11kW; 3×380-500V;In max: 25A;(7,5kW; 17A); IP20

INVERTER
SERIES FR-A800 PLUS SERIES
TYPE FR-A800-R2R (FOR ROLL TO ROLL)
MINIMUM RATED VOLTAGE (V) 380
MIN. PERMISSIBLE VOLTAGE (V) 323
MAXIMUM RATED VOLTAGE (V) 500
MAX. PERMISSIBLE VOLTAGE (V) 550
CURRENT TYPE AC
PHASES 3
RATED OUTPUT CURRENT SLD (A) 25
RATED OUTPUT CURRENT LD (A) 23
RATED OUTPUT CURRENT ND (A) 17
RATED OUTPUT CURRENT HD (A) 12
RATED MOTOR CAPACITY SLD (KW) 11
RATED MOTOR CAPACITY LD (KW) 11
RATED MOTOR CAPACITY ND (KW) 7,5
RATED MOTOR CAPACITY HD (KW) 5,5
CONTROL METHOD SOFT-PWM/HIGH FRQ PWM/VECTOR
MOTOR TYPE INDUCTION MOTOR
INTEGRATED EMC FILTER YES
SAFE TORQUE OFF (STO) YES
REGENERATIVE (4Q) NO
INTEGRATED DC CHOKE NO
DISPLAY FR-DU08
DISPLAY TYPE 5 DIGITS LED
PLC FUNCTION YES
PROGRAM MEMORY 6K
PROGRAM MEMORY UNIT STEPS
INTEGRATED DIGITAL INPUTS 12
DIGITAL OUTPUTS (TRANSISTOR) 5
DIGITAL OUTPUTS (RELAY) 2
INTEGRATED ANALOGUE INPUTS 3
INTEGRATED ANALOGUE OUTPUTS 2
TYPE OF TERMINAL BLOCK PLUG
EXPANDABLE YES
USB 2
BUILT-IN NETWORK MODBUS-RTU
PROTECTION CLASS IP00
STANDBY POWER CONSUMPTION (W) 20
LEAKAGE CURRENT (MA) 35(DELTA) / 2(STAR)
ETHERNET PORT 1
POWER LOSS SLD (W) 345
POWER LOSS LD (W) 315
POWER LOSS ND (W) 220
POWER LOSS HD (W) 165
ADDITIONAL PRODUCT INFORMATION
DIFFERENCE TO STANDARD 1 ROLL TO ROLL CONTROL
PRODUCT DIMENSIONS & WEIGHT
WIDTH (MM) 220
HEIGHT (MM) 260
DEPTH (MM) 170
WEIGHT (KG) 6,7
ORDER CODES
EUROPEAN ORDER CODE 412447
GLOBAL ORDER CODE 1AY991-0001PK
CLASSIFICATION DATA
PRODUCT HIERARCHY IAK24101
CLASS DESCRIPTION FA-Inverter: Inverter
EXTERNAL MATERIAL GROUP Standard Material
AVAILABILITY
LOGISTIC CLASS C
PACKAGING DIMENSIONS & WEIGHT
GROSS WEIGHT 7.643 KG
VOLUME 33.215 CDM
LENGTH 36,5 CM
WIDTH 35 CM
HEIGHT 26 CM
COMMODITY / IMPORT CODE
COMMODITY CODE 85371091
COUNTRY OF ORIGIN JP
LIFE CYCLE
PREDECESSOR 296468 FR-A840-00250-2-60R2R
CAMPAIGNS
SELLING STATUS Standard
ENVIRONMENTAL
ROHS COMPLIANCE COMPLIANT
DANGEROUS GOODS REGULATIONS NO
