Type: BHW-T MINI. CIRCUIT BREAKER
Series: WS-V SERIES – MCB
Serial Number: 411348
Product Details: MCB 3-pole, Rated current 100A, Operating characteristic C
MINIATURE CIRCUIT BREAKER
SERIES WS-V SERIES – MCB
TYPE BHW-T MINI. CIRCUIT BREAKER
NUMBER OF POLES 3
RATED CURRENT (A) 100
CURRENT TYPE AC
RATED VOLTAGE (V) 415
INSTANTANEOUS TRIPPING TYPE C
BREAKING CAPACITY AT 415V (KA) 10
CYCLES WITH RATED CURRENT 4000
CYCLES WITHOUT RATED CURRENT 10000
PRODUCT DIMENSIONS & WEIGHT
WIDTH (MM) 18
HEIGHT (MM) 92,6
DEPTH (MM) 73,5
WEIGHT (KG) 0,13
ORDER CODES
EUROPEAN ORDER CODE 411348
CLASSIFICATION DATA
PRODUCT HIERARCHY IAN10136
CLASS DESCRIPTION FA-MCB: Miniature Circuit Breaker
EXTERNAL MATERIAL GROUP Standard Material
AVAILABILITY
LOGISTIC CLASS B
PACKAGING DIMENSIONS & WEIGHT
GROSS WEIGHT 0.656 KG
VOLUME 0.72 CDM
LENGTH 10 CM
WIDTH 8 CM
HEIGHT 9 CM
COMMODITY / IMPORT CODE
COMMODITY CODE 85362090
COUNTRY OF ORIGIN IN
CAMPAIGNS
SELLING STATUS Standard
ENVIRONMENTAL
ROHS COMPLIANCE COMPLIANT
DANGEROUS GOODS REGULATIONS NO
