Type: BH-D MINI. CIRCUIT BREAKER
Series: WS-V SERIES – MCB
Serial Number: 247891
Product Details: Miniature circuit breaker 16 A, 3 pole, Type C
MINIATURE CIRCUIT BREAKER
SERIES WS-V SERIES – MCB
TYPE BH-D MINI. CIRCUIT BREAKER
NUMBER OF POLES 3
CURRENT TYPE AC
RATED VOLTAGE (V) 400
INSTANTANEOUS TRIPPING TYPE C
BREAKING CAPACITY AT 415V (KA) 10
CYCLES WITH RATED CURRENT 10000
CYCLES WITHOUT RATED CURRENT 10000
PRODUCT DIMENSIONS & WEIGHT
WIDTH (MM) 54
HEIGHT (MM) 87
DEPTH (MM) 70
WEIGHT (KG) 0,45
ORDER CODES
EUROPEAN ORDER CODE 247891
GLOBAL ORDER CODE D3P-016C10N
CLASSIFICATION DATA
PRODUCT HIERARCHY IAN10143
CLASS DESCRIPTION FA-MCB: Miniature Circuit Breaker
EXTERNAL MATERIAL GROUP Standard Material
AVAILABILITY
LOGISTIC CLASS B
PACKAGING DIMENSIONS & WEIGHT
GROSS WEIGHT 0.376 KG
VOLUME 0.352 CDM
LENGTH 8,7 CM
WIDTH 5,4 CM
HEIGHT 7,5 CM
COMMODITY / IMPORT CODE
COMMODITY CODE 85361050
COUNTRY OF ORIGIN CN
CAMPAIGNS
SELLING STATUS Standard
ENVIRONMENTAL
REACH LIMIT EXCEEDED NO
DANGEROUS GOODS REGULATIONS NO
