Type: REMOTE ANALOG OUTPUT
Series: CC-LINK
Serial Number:
Product Details: PLC CC-Link I/O module; 4 analog outputs +/-10 V; coated
ANALOGUE I/O MODULE
SERIES CC-LINK
TYPE REMOTE ANALOG OUTPUT
POWER SUPPLY (V) 24
CURRENT TYPE DC
OCCUPIED STATIONS 2
INTEGRATED ANALOGUE OUTPUTS 4
OUTPUT VOLTAGE RANGE (V) -10-10
WIRING SCREW
INT. CURRENT CONSUMPTION (A) 0,18
ADDITIONAL PRODUCT INFORMATION
DIFFERENCE TO STANDARD 1 COATING
PRODUCT DIMENSIONS & WEIGHT
WIDTH (MM) 152
HEIGHT (MM) 65
DEPTH (MM) 63
WEIGHT (KG) 0,4
ORDER CODES
EUROPEAN ORDER CODE 193788
GLOBAL ORDER CODE 1W5G18
CLASSIFICATION DATA
PRODUCT HIERARCHY IAD590
CLASS DESCRIPTION FA-MOD PLC: Analogue I/O Module
EXTERNAL MATERIAL GROUP End Of Life Announced Material
AVAILABILITY
LOGISTIC CLASS C
PACKAGING DIMENSIONS & WEIGHT
GROSS WEIGHT 0.495 KG
VOLUME 2.365 CDM
LENGTH 21,5 CM
WIDTH 11 CM
HEIGHT 10 CM
COMMODITY / IMPORT CODE
COMMODITY CODE 85389099
COUNTRY OF ORIGIN JP
LIFE CYCLE
DISCONTINUED (EOL) 18.09.2019
LAST TIME BUY (LTB) 10.07.2021
END OF SERVICE (EOS) 10.07.2028
CAMPAIGNS
SELLING STATUS Standard
ENVIRONMENTAL
REACH LIMIT EXCEEDED YES
REACH SUBSTANCE CAS NUMBER 1303-86-2
1317-36-8
7439-92-1
DANGEROUS GOODS REGULATIONS NO
